Tobul Bladder Accumulators

Tobul Bladder Accumulators

The typical bladder accumulator makes use of the considerable differences in the relative compressibility between a gas and a fluid. A typical design consists of a gas proof elastomer membrane enclosed within a steel shell. The membrane contains compressed gas (normally dry nitrogen) and separates the gas from the hydraulic fluid. The compressed gas provides a pneumatic spring action to force stored hydraulic fluid from the accumulator into the system as needed.


Tobul Bladder-type Accumulators

The typical bladder-type accumulator is a bottom repairable design, in that the bladder is inserted into the shell through a bottom opening in the shell. This opening allows the installation of the oil port body/poppet valve assembly to seal the accumulator. Optional top repairable designs are available, along with various gas stem sizes (7/8" & 2”) if desired. Tobul’s parts and bladder kits are interchangeable with most major manufacturers.


Stainless Steel Bladder Accumulator

  • TBRT15 Stainless Steel Bladder Accumulator, 1,500 psi, (103 bar), 2.5 through 15 gallons, top repairable only

2,000 PSI Bladder Type Accumulators

  • Econolator II Open Top, 2,000 psi

3,000 PSI Bladder Type Accumulators

  • Econolator II Open Top, 3,000 psi
  • TBR30 Accumulators, 3,000 psi (207 bar), bottom repairable
  • TBR30 Accumulators, 3,000 psi (207 bar), bottom repairable, 1 gallon (4 liter)
  • TBR30 Accumulators, 3,000 psi (207 bar), bottom repairable, 1 quart (1 liter)
  • TBRT30 Accumulators, 3,000 psi (207 bar), top repairable
  • TBRT30 Stainless Steel Accumulators, 3,000 psi (207 bar), top repairable only

5,000 PSI Bladder Type Accumulators

  • EBR50 Econolator II Open Top Accumulators, 5,000 psi
  • TBR50 Accumulators, 5,000 psi (345 bar), bottom repairable
  • TBR50-2 Accumulators, 5,000 psi (345 bar), bottom repairable
  • TBRT50 Accumulators, 5,000 psi (345 bar), top repairable
